说明
额定温度：-40～200℃
额定电压：30VAC and 60VDC
标准：DIN 72551, ISO 6722, ISO 19642
绝缘：硅橡胶
笔直火焰燃烧试验切合：DIN 72551.5
环保要求：RoHS & REACH
应用
适用于汽车内部电气系统用低压电线
参数
| Conductor 导体 | Insulation 绝缘 | Maximun Resistance at 20℃ 20℃最大导体电阻Ω/km | |||
| mm2 截面 | No./mm 线数/最大线径 | Nom.Dia. 外径 mm | Min.Thick 最小厚度 mm | Maximum outer diameter 最大外径 mm | |
| 0.35 | 12/0.21 | 0.80 | 0.48 | 2.30 | 54.40 |
| 0.50 | 16/0.21 | 0.92 | 0.48 | 2.30 | 37.10 |
| 0.75 | 24/0.21 | 1.14 | 0.48 | 2.50 | 24.70 |
| 1.00 | 32/0.21 | 1.31 | 0.48 | 2.70 | 18.50 |
| 1.50 | 30/0.26 | 1.58 | 0.48 | 3.00 | 12.70 |
| 2.00 | 28/0.31 | 1.83 | 0.48 | 3.30 | 9.42 |
| 2.50 | 50/0.26 | 2.04 | 0.56 | 3.60 | 7.60 |
| 3.00 | 44/0.31 | 2.30 | 0.56 | 4.10 | 6.15 |
| 4.00 | 56/0.31 | 2.60 | 0.64 | 4.40 | 4.71 |
| 5.00 | 65/0.33 | 2.90 | 0.64 | 4.90 | 3.94 |
| 6.00 | 84/0.31 | 3.18 | 0.64 | 5.00 | 3.14 |
| 10.00 | 80/0.41 | 4.13 | 0.80 | 6.50 | 1.82 |
| 16.00 | 126/0.41 | 5.20 | 0.80 | 8.30 | 1.16 |
| 25.00 | 196/0.41 | 6.75 | 1.04 | 10.40 | 0.743 |
| 35.00 | 276/0.41 | 8.09 | 1.04 | 11.60 | 0.527 |
| 50.00 | 396/0.41 | 9.70 | 1.20 | 13.50 | 0.368 |
| 70.00 | 557/0.41 | 11.40 | 1.20 | 15.50 | 0.259 |
| 95.00 | 757/0.41 | 13.26 | 1.28 | 18.00 | 0.196 |
| 120.00 | 969/0.41 | 15.00 | 1.28 | 19.70 | 0.153 |
